VIS Motorsport High Pressure Fuel Pump Upgrade Kit Stage3 VW Golf MK6 R MK5 GTI

VIS Motorsport High Pressure Fuel Pump Upgrade Kit 2.0TFSi - EA113 - STAGE 3

THIS IS THE STAGE 3 PUMP - ONLY REQUIRED WHEN PUSHING 600+BHP

Modification of the 2.0TFSi EA113 engines far beyond OEM power level requires an additional volume of high-pressure fuel in order to avoid "fuel cuts" especially in the midrange

In many cases we see the factory fuel pump begin to suffer from pressure loss.The limitation of how much volume of fuel the high pressure pump can flow is dependent upon the volume displaced by the pressurizing cylinder inside the pump.

This upgrade replaces the internal parts that are responsible for pressure and volume of fuel that reaches your injectors to meet the demands that come for higher power.

Tolerances involved, the final surface finish on the piston inside the fuel pump is so critical that it can be damaged by touching them with bare hands. The tolerances between the piston and the new sleeve the piston rides in can only be measured by a machine which uses air volumes to measure the part clearances to within microscopic levels.

CMM coordinate measuring machine is a device for measuring the physical geometrical characteristics of an object and used here with success.​

The big difference between the stage 2 and stage 3 internals are the pressures they can go up to, the stage 2 internals are 175bar, and stage 3 is 200bar if the hardware fitted to the car will allow it!

Features:

• Piston has over than 55% / 75% area than OEM

• Piston head optimized for ideal fuel flow direction

• Piston surface hardened and heat treated in 3 different stages

• Uses OEM-style spring keeper, not a higher rated one that will prematurely wear the cam follower

• Get the most out of the direct injection fuelling system on your 2.0T FSI. Not only does the upgrade increase the amount of fuel your high pressure fuel pump can deliver but it will also decrease the duty cycle of the N276 solenoid on your pump. Lowering the duty cycle of the N276 will extend the life of this solenoid, an item that commonly fails on these pumps but isn't available separately.

• Even a standard stock or Stage 1 car will see benefits from running these internals

• Can sustain easyily 600 hp, over 200 bar if hardware setup allow!

• Laser marked for better traceability and protection from fake replica

• Pump housing O ring made of Viton

• 10.7MM

• This is for the people who would like the internals on there own. Can be supplied with new Genuine fuel pump for extra
